Venturi desuperheater
Venturi desuperheater
Venturi Desuperheaters reduce gas temperature by bringing superheated gas into direct contact with a liquid, typically this can be a steam/water combination. The gas is cooled through the evaporation of the liquid. These desuperheaters are recommended for use under a wide range of conditions, including steady and variable flows.
Specifications
Materials body
Forged material SA105, SA182 F11/F22*
Materials nozzle
SA182 F316(L)*
Pipe connection
Flanged or Butt weld end
Temperatures
Up to 600°C (based upon selected material)
Pressure
Available in ASME and EN Pressure Classes
Diameters upon request
Codes
ASME 31.1, ASME 31.3, ASME B16.34, PED**
* Other materials on request
(i.e. austenitic, special alloy)
** EN equivalent available
Our Venturi desuperheater can be used in the oil- and gasindustry
