Sample cooler with hot bath
Sample cooler with hot bath
Den Holder designs and manufactures sample Coolers with Hot Bath, which are designed in accordance with our client’s requirements or any international standard.
The coils can be supplied in any material with the in- and outlet connections in any required position. Execution of the in- and outlet is SW as standard, but can be also be delivered flanged or threaded, The Coolers can optionally be delivered with support legs or mounting brackets.
Den Holder can manufacture Sample Coolers and Sample Cabinets with Hot Bath in any required material or diameter and /or design.
Specifications
Materials body
Standard in CS
Materials coil
A106Gr.B
A335Gr.P5/P11/P22
A312TP304(L)/316(L)/316Ti/321(H)
Monel
Hastelloy
Coil sizes
1/2”
3/4”
1”
Design codes
ASME B31.3
clients requirements
Stand tests
Hydrotest of coil
LPE/MPE
Optional
100% X-ray of welds
Stainless steel body
Pickling and passivating
Shotblasting and coating with any paint system
Our Sample coolers with hot bath can be used in the oil and gas industry
